No Keys Required: Inside the Attack Surface of xLLM

A deep dive into the architecture and vulnerability classes hiding inside production LLM inference engines, through the lens of xLLM.

Security Research - July 2026

LLM inference engines are a strange breed of software. They are built by ML engineers who think in tensors and throughput, deployed on GPU clusters worth millions, and then exposed to the internet through an HTTP API that trusts every byte it receives. The result is an attack surface that feels less like a web application and more like an industrial control system that someone accidentally port-forwarded.

xLLM is a high-performance, open-source LLM inference engine written in C++ on top of Apache brpc. It supports the full OpenAI and Anthropic API surface, handles multimodal inputs (vision, audio, video), and runs distributed multi-GPU inference with disaggregated prefill-decode scheduling. It powers deployment of Qwen, DeepSeek, LLaMA, and dozens of other model families. It was recently donated to the OpenAtom Foundation.

We spent three rounds auditing its codebase. What we found says less about xLLM specifically and more about a systemic pattern across the entire LLM serving ecosystem.

The Architecture, Through an Attacker's Eyes

Before looking at individual bugs, it helps to understand why the attack surface of an inference engine looks the way it does. Three architectural properties shape everything that follows.

Property 1: Multiple network listeners, zero authentication

xLLM is not a single-port web server. In a production distributed deployment, a single node can bind seven or more brpc server ports:

graph TB
  subgraph "Single xLLM Node"
    API["Main API\nport 8010\nHTTP + brpc"]
    PD["DisaggPD\nport 7777\nprefill-decode RPC"]
    W1["Worker 0\nauto-assigned\nmodel execution"]
    W2["Worker 1\nauto-assigned\nmodel execution"]
    MC["MooncakeTransfer\nport 26000\nKV cache shipping"]
    XT["XTensorDist\ndynamic\npage pool ops"]
    CO["Collective\ndynamic\nNCCL sync"]
  end
  EXT["External Client"] --> API
  NODE2["Other xLLM Nodes"] --> PD
  NODE2 --> MC
  NODE2 --> XT

Every one of these ports speaks brpc's HTTP and protobuf-over-TCP protocols. We grepped the entire xllm/ tree for auth, token, api_key, bearer, Authorization, credential, password, allowlist, blocklist. Zero results. We checked every brpc::ServerOptions instance for TLS or auth configuration. Nothing. We checked the protobuf message definitions for auth-related fields. None.

The sole gating mechanism we found was enable_online_profile (a feature flag for the CPU profiler, default off, not an auth check) and a RateLimiter that caps concurrent requests at 200 without distinguishing users.

This means the management endpoints - fork_master (load a model from any filesystem path), sleep/wakeup (unload/reload models), pause (abort all in-flight requests), link_p2p (establish connections to arbitrary addresses) are accessible to anyone who can reach the port.

Property 2: The multimodal surface is a proxy

When serving vision-language models, xLLM's API accepts URLs in image_url, video_url, and audio_url fields. The server fetches these URLs server-side to download the media content before passing it to the model. This turns the inference engine into an HTTP proxy that makes outbound requests on behalf of the client a classic SSRF surface.

What makes this surface particularly interesting in LLM engines is the multimodal decode pipeline. The fetched bytes go through format-specific decoders (OpenCV for images, FFmpeg for video/audio). The decoder output becomes a tensor that feeds the model. The model's text output is returned to the client. This creates an indirect data channel: if the attacker can control what the model sees, they can influence what the model says.

Property 3: brpc's builtin services are opt-out

Apache brpc is a high-performance RPC framework used widely in Chinese tech infrastructure (Baidu, JD, ByteDance). One of its features is a built-in debug console: /flags (view/modify all gflags), /vars (internal metrics), /connections (active connections), /pprof/* (CPU/heap profiling), /status. These are enabled by default on every server port unless the developer explicitly sets has_builtin_services = false.

This is the brpc equivalent of leaving Django's DEBUG=True in production except it exposes runtime flags that can be modified, not just read.

Mapping the Attack Surface

With the architecture understood, here is how we decomposed the surface. Each category represents a different trust boundary the engine fails to enforce.

graph LR
  subgraph "Attack Surface Categories"
    S1["1. Inference API\nuser prompts, tokens,\nsampling params"]
    S2["2. Multimodal Fetch\nURLs, headers,\nfile:// paths"]
    S3["3. Management Plane\nfork_master, sleep,\npause, link_p2p"]
    S4["4. brpc Builtins\n/flags, /pprof,\n/connections"]
    S5["5. Inter-node RPC\nworker comms,\nKV transfer, sync"]
    S6["6. Local IPC\nshared memory,\n0666 perms"]
  end
  S1 --> SINK1["Scheduler +\nModel Execution"]
  S2 --> SINK2["SSRF / LFI"]
  S3 --> SINK3["Lifecycle Control"]
  S4 --> SINK4["Config Leak +\nFlag Modification"]
  S5 --> SINK5["Data Injection"]
  S6 --> SINK6["OOB Read/Write"]

Categories 1 and 5-6 turned out to be well-defended or require non-default configurations. Categories 2-4 produced four confirmed findings. The interesting story is in both: what broke and what held.

The Multimodal Proxy: Blind SSRF with Header Forwarding

The first thing we traced was the multimodal URL fetch path. In mm_handler.cpp, the ImageHandler::load() method dispatches on URL prefix:

// xllm/core/framework/multimodal/mm_handler.cpp:112-138
MMErrCode ImageHandler::load(const MMContent& content,
                             MMInputItem& input,
                             MMPayload& payload) {
  const auto& url = content.image_url.url;

  if (url.compare(0, dataurl_prefix_.size(), dataurl_prefix_) == 0) {
    return this->load_from_dataurl(url, input.raw_data, payload);

  } else if (url.compare(0, httpurl_prefix_.size(), httpurl_prefix_) == 0) {
    // "http://..." or "https://..." - server fetches the URL
    return this->load_from_http(url, input.raw_data,
                                content.image_url.headers);  // <---

  } else {
    // everything else: treat as local file path
    if (this->load_from_local(url, input.raw_data) == MMErrCode::SUCCESS) {
      return MMErrCode::SUCCESS;
    }
    return MMErrCode::INVALID_URL_ERR;
  }
}

The httpurl_prefix_ is the 4-character string "http". Any URL starting with http both http:// and https:// enters the server-side fetch path. The URL flows through load_from_http() into BRpcDownloader::download():

// xllm/core/util/http_downloader.cpp:109-144
bool BRpcDownloader::download(
    const std::string& host, const std::string& url,
    std::string& data,
    const std::unordered_map<std::string, std::string>& headers) {

  brpc::Controller cntl;
  cntl.http_request().uri() = url;          // attacker URL, verbatim

  for (const auto& [k, v] : parse_global_headers()) {
    cntl.http_request().SetHeader(k, v);    // global defaults
  }
  for (const auto& [k, v] : headers) {
    cntl.http_request().SetHeader(k, v);    // per-request: attacker-controlled
  }

  cntl.set_timeout_ms(2000);
  auto channel = get_channel(host);
  channel->CallMethod(nullptr, &cntl, nullptr, nullptr, nullptr);
  // ...
}

The parse_url() function (line 60) that runs before this does one thing: it splits the URL at :// and the next / to extract the host. No validation of the host. No check against private IP ranges. No scheme restriction. No redirect following limit. The URL goes straight to brpc::Channel::Init(host) and then CallMethod.

The critical detail is the headers parameter. It comes from the protobuf definition at multimodal.proto:28:

// xllm/proto/multimodal.proto
message ImageURL {
  string url = 1;
  map<string, string> headers = 2;   // attacker-controlled key-value pairs
}

These headers are extracted at mm_service_utils.h:50-51 and forwarded verbatim to the outbound request. An attacker can include Authorization, Cookie, or any other header, turning the blind SSRF into an authenticated proxy for internal services.

graph LR
  REQ["POST /v1/chat/completions\n{image_url: {url, headers}}"] --> PARSE["api_service.cpp:421\nJsonToProtoMessage"]
  PARSE --> EXTRACT["mm_service_utils.h:47\nextract URL + headers map"]
  EXTRACT --> DISPATCH["mm_handler.cpp:125\nprefix == http ?"]
  DISPATCH --> HTTP["load_from_http()"]
  HTTP --> DL["http_downloader.cpp:115\ncntl.uri() = url\nSetHeader(k, v) per header"]
  DL --> OUT["Outbound HTTP\nto attacker-specified host\nwith attacker-specified headers"]

The SSRF is blind for non-image responses. Cloud metadata endpoints return JSON, which fails OpenCV's imdecode(), and the client sees only "Failed to decode multimodal input." But "blind" here still means the attacker can distinguish four states via timing and error differentiation: connection refused (~1ms), connection timeout (2000ms), HTTP 200 with non-image data (DECODE_ERR), and HTTP 200 with valid image (the VLM processes it). This enables reliable port scanning and service fingerprinting of the internal network.

This is the exact same bug class as CVE-2025-6242 in vLLM. The pattern is systemic: every LLM engine that fetches multimodal URLs server-side without validation inherits this surface.

The Debug Console Nobody Turned Off

Every brpc::ServerOptions in xLLM is default-constructed. The field has_builtin_services is never touched:

// xllm/server/xllm_server.cpp:141-150
brpc::ServerOptions options;
options.idle_timeout_sec =
    ::xllm::ServiceConfig::get_instance().rpc_idle_timeout_s();
options.num_threads = ::xllm::ServiceConfig::get_instance().num_threads();
options.health_reporter = &HealthReporter::instance();
// has_builtin_services is never set - brpc defaults it to true
if (server_->Start(port, &options) != 0) { ... }

The same pattern at line 269 (the generic create_server() used for DisaggPD, Collective, Worker, and XTensorDist servers) and at mooncake_transfer_engine.cpp:152. We grep'd for has_builtin_services and internal_port across the entire codebase: zero hits.

The consequence is that every brpc port exposes the full builtin suite. GET /flags dumps all 189 xLLM gflags plus brpc's own, including model paths, network addresses, etcd endpoints, and config file locations. GET /pprof/cmdline reads /proc/self/cmdline and returns the complete startup command with all arguments. GET /connections reveals the internal cluster topology.

And because FLAGS_immutable_flags is also never set, flags can be modified at runtime via GET /flags/<name>?setvalue=<val>.

The singleton firewall

We investigated whether flag modification could escalate to RCE. The answer is no, and the reason is architecturally interesting. xLLM copies all flag values into singleton config objects at startup:

// Config initialization pattern (simplified)
// At startup:
ModelConfig::get_instance().initialize();  // reads FLAGS_model, FLAGS_backend, etc.

// At runtime, all application code reads from the singleton:
auto path = ModelConfig::get_instance().model_path();  // not FLAGS_model

After initialization, the singletons are immutable. Modifying FLAGS_model, FLAGS_python_model_path, FLAGS_enable_xtensor, or FLAGS_enable_shm via /flags has zero effect on running behavior. The flags that are read live are brpc's own: setting FLAGS_max_body_size to 0 makes brpc reject all subsequent requests ("message too large"), a persistent DoS that requires no restart. Setting FLAGS_minloglevel to 3 silences all logs.

Accidental defense-in-depth. The singleton config pattern was almost certainly designed for performance (avoid re-reading flags on every request), not security. But it creates an effective firewall between the /flags endpoint and the application's critical state. Many brpc-based services read FLAGS_ directly, where this same exposure would be catastrophic.

The Other Branch: Arbitrary File Read

Back to the three-way URL dispatch in ImageHandler::load(). The else-branch at line 130 is the interesting one: everything that does not start with "data:image" or "http" falls through to load_from_local(). Since "file"[0] != "http"[0], any file:// URL and any bare absolute path reaches this code:

// xllm/core/framework/multimodal/mm_handler.cpp:82-98
MMErrCode MMHandlerBase::load_from_local(const std::string& url,
                                         std::string& data) {
  std::string path = url;
  const std::string prefix = "file://";
  if (path.compare(0, prefix.size(), prefix) == 0) {
    path = path.substr(prefix.size());     // strip "file://", that's it
  }

  std::ifstream in(path, std::ios::binary);
  if (!in) {
    LOG(ERROR) << "failed to open local file: " << path;
    return MMErrCode::LOAD_LOCAL_ERR;
  }

  data.assign(std::istreambuf_iterator<char>(in),
              std::istreambuf_iterator<char>());
  return MMErrCode::SUCCESS;
}

No allowlist. No chroot. No symlink resolution. No ../ filtering. No file size limit. The istreambuf_iterator reads until EOF. The bytes go into data, then to cv::imdecode().

We spent a full investigation round trying to upgrade this to full content exfiltration. The results were definitive: OpenCV's decode pipeline (imdecode + convert_decoded_image_to_rgb) strips all metadata. EXIF, PNG tEXt chunks, nothing survives. Non-image files produce an empty cv::Mat and a generic decode error. The raw bytes are in server memory but never returned to the client.

What does work:

• File existence oracle. Two distinct error messages: DECODE_ERR ("Failed to decode multimodal input") when the file exists but is not a valid image, INVALID_URL_ERR ("url must be data URL / http(s) URL / local file URL") when the file does not exist. This allows enumerating the filesystem, including /proc/self/environ, /proc/self/maps, and open file descriptors at /proc/self/fd/<N>.
• Image exfiltration via VLM. If the file at the target path happens to be a valid PNG, JPEG, or BMP, it is decoded, passed to the vision-language model, and the model's description is returned to the client. Screenshots, charts, photos anything the server process can read and OpenCV can decode.
• OOM crash. Pointing the URL at /dev/zero causes the istreambuf_iterator to read forever, allocating memory until the kernel OOM-kills the process.

graph TD
  INPUT["image_url: file:///target/path"] --> STRIP["load_from_local()\nstrip file:// prefix"]
  STRIP --> OPEN["std::ifstream(path)\nno validation"]
  OPEN -->|"file exists"| READ["istreambuf_iterator\nread entire file\nno size limit"]
  OPEN -->|"file missing"| E1["LOAD_LOCAL_ERR"]
  READ --> DECODE["cv::imdecode()"]
  DECODE -->|"valid image"| VLM["VLM processes image\nmodel describes content\nreturned to attacker"]
  DECODE -->|"not image"| E2["DECODE_ERR\ngeneric error"]
  OPEN -->|"/dev/zero"| OOM["istreambuf_iterator\nreads forever\nOOM kill"]

Note that only ImageHandler has this local-file fallback. VideoHandler::load() and AudioHandler::load() return INVALID_URL_ERR for non-data/non-http URLs.

One Header to Kill Them All

This one is the smallest finding and the most reliable. xLLM defines a custom HTTP header, Infer-Content-Length, used to split a request body into a JSON region and a binary multimodal payload region. The header value is parsed by get_json_content_length():

// xllm/api_service/api_service.cpp:301-315
size_t get_json_content_length(const brpc::Controller* ctrl) {
  const auto infer_content_len =
      ctrl->http_request().GetHeader(kInferContentLength);
  if (infer_content_len != nullptr) {
    return std::stoul(*infer_content_len);   // throws on non-numeric input
  }

  const auto content_len = ctrl->http_request().GetHeader(kContentLength);
  if (content_len != nullptr) {
    return std::stoul(*content_len);         // same pattern
  }

  LOG(ERROR) << "Content-Length header is missing.";
  return (size_t)-1L;
}

std::stoul throws std::invalid_argument for non-numeric input and std::out_of_range for overflow. There is no try-catch here. There is no try-catch in any caller. There is no try-catch in brpc's service dispatch - service methods run in bthreads, and an uncaught exception in a bthread invokes std::terminate().

The same pattern repeats at call.cpp:50-51 in Call::init_request_payload(), which runs for every endpoint that processes a request body.

A single HTTP request with Infer-Content-Length: AAAA terminates the entire server process. Every in-flight request from every user dies with it. The header is non-standard, so no reverse proxy validates or strips it.

graph LR
  REQ["HTTP request with\nInfer-Content-Length: AAAA"] --> PARSE["get_json_content_length()\napi_service.cpp:305"]
  PARSE --> STOUL["std::stoul('AAAA')"]
  STOUL --> THROW["throws std::invalid_argument"]
  THROW --> TERM["std::terminate()\nabort()"]
  TERM --> DEAD["Server process killed\nall connections dropped"]

What Held Up

A security audit that only reports what broke is incomplete. The surfaces we investigated and found well-defended tell us as much about the system's security posture as the vulnerabilities do.

Safetensors model loading. Model weights are parsed by a Rust crate (safetensors v0.6.0) compiled as a static library with C FFI bindings. The Rust parser validates JSON header sizes, tensor offset/size boundaries, and dtype values before the C++ consumer at state_dict.cpp ever sees the data. Memory-mapped files use MAP_PRIVATE | PROT_READ. There is no pickle.loads, no torch.load, no GGUF parser. This is the most secure model weight loading we have seen in any inference engine.

Jinja chat templates. The minja C++ Jinja library receives user messages as structured nlohmann::ordered_json data at jinja_chat_template.cpp:76-113. The template itself is loaded from the model's tokenizer_config.json at initialization and is never user-controlled. Jinja's rendering pipeline treats {{ }} and {% %} in data values as literal text, not template directives. No SSTI.

Binary multimodal payload parsing. The binary,<length> data URL format uses butil::StringToSizeT() for length parsing (rejects non-numeric, handles overflow) and MMPayload::get() bounds-checks against available data. No integer overflow, no OOB read.

HTTP request smuggling. xLLM's brpc fork is based on version 1.12.1, past the CVE-2024-23452 fix in 1.8.0. The custom Infer-Content-Length header only affects how xLLM reads from brpc's already-consumed body buffer (request_attachment()), not the TCP stream. No desync possible.

Sampling parameter validation. Temperature is clamped to [0.0, 2.0] at request_params.cpp:597. Zero temperature is gracefully replaced with 1.0 at logits_utils.cpp:64. Top-k is clamped to vocab size. Token lengths are validated by the scheduler against the model's max context length. NaN values via raw protobuf (not HTTP/JSON) can bypass range checks, but the impact is limited to single-request output corruption, not a crash.

Shared memory IPC. The ForwardSharedMemoryManager creates segments with mode 0666 and predictable names, and its read functions (read_string, read_vector, read_tensor) lack bounds checking. This is technically exploitable by a local attacker. But enable_shm defaults to false, so the segments are never created in default deployment. The vulnerability is real but conditional on a non-default performance optimization flag.

The Systemic Pattern

None of the bugs we found required a novel exploitation technique. SSRF, path traversal, information disclosure, uncaught exception these are textbook classes that web application security has understood for two decades. What is interesting is not the individual bugs but the architectural assumptions that produced all four simultaneously.

LLM inference engines occupy a strange middle ground in the software stack. They are built like internal infrastructure no auth, management APIs wide open, debug surfaces enabled, inter-node communication in plaintext but deployed at the trust boundary of a public-facing API. The implicit threat model is "the network is trusted." When that assumption fails, every surface fails at once.

This is not unique to xLLM. The same pattern produced:

• CVE-2025-6242 - vLLM SSRF via MediaConnector.load_from_url(), the exact same bug class.
• CVE-2024-50050 - Meta Llama Stack pickle deserialization over an unauthenticated ZMQ socket.
• CVE-2025-30165 - vLLM pickle deserialization over ZMQ, same pattern.
• CVE-2025-23254 - NVIDIA TensorRT-LLM, same pattern.

The LLM serving ecosystem is replaying the early web framework era: ship for throughput, authenticate later. The difference is that the blast radius is larger an inference engine compromise exposes model weights, user prompts, internal network topology, and cloud credentials and the "later" keeps not arriving.

The assumption that "the network is trusted" is load-bearing in every design decision. When that assumption fails, everything fails at once. The fix is not to patch individual bugs. The fix is to stop building inference engines like they will only ever run inside a VPN.

One bright spot: xLLM's Rust-based safetensors parser and its accidental singleton config firewall show that defense-in-depth can emerge even without deliberate security engineering. The lesson is to make it deliberate.

References

• xLLM source: github.com/xLLM-AI/xllm (Apache 2.0, commit 37413cfe)
• vLLM SSRF: CVE-2025-6242
• brpc builtin services RCE: CVE-2025-60021
• brpc HTTP smuggling: CVE-2024-23452
• Meta Llama pickle deser: CVE-2024-50050
• Research conducted with Claude Code. Agent fleet parallelized surface enumeration and adversarial cross-verification; human judgment drove threat modeling and severity assessment.
